功能特点：
1.DSP A18 控制系统，实现真正意义4轴联动！
2.机身加厚焊接处理，比普通机身强度提高35%，钢制托式大龙门，运行平稳。
3.下沉式高承重机身，进料可超过1M，稳固不变形
4.台湾进口上银/银泰方轨，市场运用多年，质量有保证
5.具有断点，断电续雕功能，铝型材台面，压板固定雕刻材料，也可根据客户要求定做真空吸附台面
技术参数：
|
Model |
SKW-1325F |
|
Working area (X*Y*Z) |
1300*2500*500mm |
|
Body structure |
seamless welded steel
structure,PVC t-slot table |
|
X, Y Structure |
rack and pinion transmission,
Taiwan hiwin square rails |
|
Z Structure |
Taiwan original TBI ball screw |
|
Max Moving Speed |
35000mm/min |
|
Max Engraving Speed |
24000mm/min |
|
XYZ traveling positioning accuracy |
±0.01mm |
|
Spindle power |
3.2KW water cooling
/3.5KW aircold spindle
(4.5KW/ 5.5KW/ 6KW/9KW Optional) |
|
Spindle Speed |
0-24,000rpm |
|
Inverter |
Fuling Inverter
(Delta Inverter Optional) |
|
Voltage |
380V/415V 3 Phase
50/60Hz(Optional:220V
Single/3 Phase 50/60Hz
or 110V Single Phase 50/60Hz ) |
|
Drive type |
stepper motors& leadshine
drivers(leadshine/YASKAWA
servo optional) |
|
Working Dictate |
G Code |
|
Operating system |
NC-studio (DSP A11 Control
System/Mach3 control
system optional) |
|
software |
Artcam(Type 3/ JDpaint
optional) |
|
Tool sensor |
Yes,included |
|
Auto oil lubricator |
Yes,included |
|
Running Environment |
Temperature: 0℃~45℃ |
|
Relative humidity |
30%-75% |
|
Package size |
3.73*2.2*1.89M |
|
G.W |
1280KGS |
|
Model |
SKW-1325F |
|
Working area (X*Y*Z) |
1300*2500*500mm |
|
Body structure |
seamless welded steel
structure,PVC t-slot table |
|
X, Y Structure |
rack and pinion transmission,
Taiwan hiwin square rails |
|
Z Structure |
Taiwan original TBI ball screw |
|
Max Moving Speed |
35000mm/min |
|
Max Engraving Speed |
24000mm/min |
|
XYZ traveling positioning accuracy |
±0.01mm |
|
Spindle power |
3.2KW water cooling
/3.5KW aircold spindle
(4.5KW/ 5.5KW/ 6KW/9KW Optional) |
|
Spindle Speed |
0-24,000rpm |
|
Inverter |
Fuling Inverter
(Delta Inverter Optional) |
|
Voltage |
380V/415V 3 Phase
50/60Hz(Optional:220V
Single/3 Phase 50/60Hz
or 110V Single Phase 50/60Hz ) |
|
Drive type |
stepper motors& leadshine
drivers(leadshine/YASKAWA
servo optional) |
|
Working Dictate |
G Code |
|
Operating system |
NC-studio (DSP A11 Control
System/Mach3 control
system optional) |
|
software |
Artcam(Type 3/ JDpaint
optional) |
|
Tool sensor |
Yes,included |
|
Auto oil lubricator |
Yes,included |
|
Running Environment |
Temperature: 0℃~45℃ |
|
Relative humidity |
30%-75% |
|
Package size |
3.73*2.2*1.89M |
|
G.W |
1280KGS |
适用行业及材料：
1.木工行业：立体波浪板加工，橱柜门、实木门、工艺木门、免漆门，屏风、工艺扇窗加工，擦鞋机，游戏机机柜及
面板，麻将桌，电脑桌及板式家俱产品的辅助加工。
2.广告行业：广告标牌、标识制作、压克力切割吸塑制模、多种广告材料及装饰产品的制作。
3.模具行业：可以雕刻铜、铝、铁等金属模具，以及人造大理石、沙石、塑料板、PVC管材、木板等非金属模具。
4.其他行业：可以雕刻各种影像、浮雕，广泛应用于工艺礼品行业
