主要特点：
1.机器整体铸铁机身，底盘稳定性高承重，长期使用永不变形，保证金属加工精度要求
2. 特殊金属主轴可选主轴永久动力，寿命长，功率大，加工精度提高20%
3、采用进口滚珠丝杆，咬合紧密，有效满足金属加工精度要求，提高金属加工精度
4.台湾方轨，支持移动台面，大大提高精度，森科样品测试最小成型0.5MM！
5. T型槽台，适用于各种材料，夹具帮助固定雕刻材料
6.机器与水槽、水龙头和水泵配套配件，能及时给机器降温，有效保护主轴、材料、刀具
技术参数：
|
Model |
SKM-4040 |
SKM-6060 |
SKM-6090 |
|
Working Area |
400*400MM |
600*600MM |
600*900MM |
|
Table Surface |
Cast iron T-slot table with water tank |
Cast iron T-slot table with water tank |
Cast iron T-slot table with water tank |
|
Frame |
Strong Cast Iron |
Strong Cast Iron |
Strong Cast Iron |
|
X Y Structure |
Ball Screw Drive, HIWIN Rail Linear Bearings |
Ball Screw Drive, HIWIN Rail Linear Bearings |
Ball Screw Drive, HIWIN Rail Linear Bearings |
|
Z Structure |
Taiwan Original TBI Ball Screw |
Taiwan Original TBI Ball Screw |
Taiwan Original TBI Ball Screw |
|
Spindle Power |
2.2KW Professional Metal Used Spindle(3.2KW 4.5KW Optional) |
2.2KW Professional Metal Used Spindle(3.2KW 4.5KW Optional) |
2.2KW Professional Metal Used Spindle(3.2KW 4.5KW Optional) |
|
Spindle Speed |
0-24000RPM |
0-24000RPM |
0-24000RPM |
|
Inverter |
Fuling Inverter(Delta Inverter Optional) |
Fuling Inverter(Delta Inverter Optional) |
Fuling Inverter(Delta Inverter Optional) |
|
Diver Motors |
Stepper motors and Leadshine Drivers(Servo Motor Optional) |
Stepper motors and Leadshine Drivers(Servo Motor Optional) |
Stepper motors and Leadshine Drivers(Servo Motor Optional) |
|
Working voltage |
380V/415V 3 Phase 50/60Hz(Optional:220V Single/3 Phase 50/60Hz or 110V Single Phase 50/60Hz ) |
380V/415V 3 Phase 50/60Hz(Optional:220V Single/3 Phase 50/60Hz or 110V Single Phase 50/60Hz ) |
380V/415V 3 Phase 50/60Hz(Optional:220V Single/3 Phase 50/60Hz or 110V Single Phase 50/60Hz ) |
|
Command Language |
G Code |
G Code |
G Code |
|
Operating System |
DSP A11 Control System (Mach 3,NK280 Optional) |
DSP A11 Control System (Mach 3,NK280 Optional) |
DSP A11 Control System (Mach 3,NK280 Optional) |
|
Software Compatibility |
Artcam (Type 3/UcancameV9 Software) |
Artcam (Type 3/UcancameV9 Software) |
Artcam (Type 3/UcancameV9 Software) |
|
Computer Interface |
USB |
USB |
USB |
|
Running Environment Temperature |
0-45 Centigrade |
0-45 Centigrade |
0-45 Centigrade |
|
Relative Humidity |
30%-75% |
30%-75% |
30%-75% |
|
After packed size |
1.18×1.03×2.13M |
1.38×1.23×2.13M |
1.68×1.23×2.13M |
|
G.W |
430KGS |
470KGS |
520KGS |
|
PS: All the working area and specifications can be customized according to your jobs requirement,And Separate control box available |
