玻璃镜子雕刻切割一体机
玻璃雕刻切割一体机
Technical Parameter:
|
Model |
SKQ-1325 |
|
X,Y,Z axis workin g area |
1300*2500*150mm |
|
X,Y movement |
Rack and pinion |
|
Z movement |
Ballscrew transmission |
|
guide |
Taiwan HIWIN/PMI 20 square rails |
|
Max idling speed |
40000mm/min |
|
Max engraving speed |
20000mm/min |
|
heads |
As needed |
|
Drive motors |
Stepper motor (servo motors optional) |
|
drivers |
Stepper drivers or servo drivers |
|
Control system |
NC-STDUIO (dsp optional) |
|
Working voltage |
220V/380V or customized |
|
Command code |
G code |
|
software |
Artcam,type 3,etc |
|
Packing dimension |
3.2*2*1.78M |
|
weight |
120kgs | |
|
