Features:
1. High accuracy for high precision parts and letter cutting.
2. Fast speed: 100 times speed than wire cutting.
3. Small hot affecting area keeps flat and nice cutting line.
4. High performance to price ratio: the price is only 1/3 of that of CO2 laser cutter and 2/5 of that of CNC.
6. Low maintenance cost: only 1/10~1/15 of same power CO2 laser cutting machine, only 1/3~1/4 of same power.
7. Top Best stable performance fiber module.
|
Model |
SKL-1530F |
SKL-2030F |
SKL-2040F |
|
Working area (X*Y*Z) |
1500*3000mm |
1500*3000mm |
1500*3000mm |
|
Body structure |
Thicken steel made lathe |
Thicken steel made lathe |
Thicken steel made lathe |
|
X, Y Structure |
gear rack |
gear rack |
gear rack |
|
rails |
Taiwan HIWIN 25 size square rails |
Taiwan HIWIN 25 size square rails |
Taiwan HIWIN 25 size square rails |
|
Z Structure |
Taiwan TBI ball screw |
Taiwan TBI ball screw |
Taiwan TBI ball screw |
|
Max Moving Speed |
70000mm/min |
70000mm/min |
70000mm/min |
|
Max Engraving Speed |
50000mm/min |
50000mm/min |
50000mm/min |
|
POWER |
MAX 1000W(1500w/2000W optional) |
MAX 1000W(1500w/2000W optional) |
MAX 1000W(1500w/2000W optional) |
|
motor |
Leadshine 1500w servo motor and driver (Japan YASKAWA optional) |
Leadshine 1500w servo motor and driver (Japan YASKAWA optional) |
Leadshine 1500w servo motor and driver (Japan YASKAWA optional) |
|
Voltage |
G Code |
G Code |
G Code |
|
Drive type |
（au3tech) SC2000 software |
（au3tech) SC2000 software |
（au3tech) SC2000 software |
|
Working Dictate |
Yes ,included |
Yes ,included |
Yes ,included |
|
Operating system |
Yes, included |
Yes, included |
Yes, included |
|
software |
Yes ,included |
Yes ,included |
Yes ,included |
|
Tool sensor |
Temperature: -10℃～45℃ |
Temperature: -10℃～45℃ |
Temperature: -10℃～45℃ |
|
oil lubricator |
yes |
yes |
yes |
|
Running Environment |
0-45 |
0-45 |
0-45 |
|
G.W |
2800KGS |
3800KGS |
4300KGS |
|
PS: All the working area and specifications can be customized according to your jobs requirement |
