SenKe Glass Mirror Cutting Machine, which suitable for different shapes cutting.
Single or multi professional glass mirror cutting heads for choose, professional vacuum table to fix thin glass mirror sheets.
As for the models which you concerned, details please find below.
|
Model |
SKQ-1313 |
SKQ-1325 |
|
Cutting area (X*Y) |
1300*1300mm |
1300*2500mm |
|
X Y Z Movement |
Imported Gear Rack |
Imported Gear Rack |
|
Z Structure |
Taiwan ball screw |
Taiwan ball screw |
|
XYZ rails |
Taiwan HIWIN square rails |
Taiwan HIWIN square rails |
|
Max Moving Speed |
20000mm/min |
20000mm/min |
|
Max Engraving Speed |
12000mm/min |
12000mm/min |
|
Voltage |
220v/single or 380v/3phase or as customer needed |
220v/single or 380v/3phase or as customer needed |
|
Drive type |
Stepper motors and leadshine drivers |
Stepper motors and leadshine drivers |
|
Working Dictate |
G Code |
G Code |
|
Operating system |
Professional Glass cutting operating system |
Professional Glass cutting operating system |
|
Software |
Professional Glass cutting software |
Professional Glass cutting software |
|
Working table |
Professional glass protection working table |
Professional glass protection working table |
|
Minimum glass size |
1x1mm |
1x1mm |
|
Wire protect |
Yes,included |
Yes,included |
|
Package |
Export wooden box |
Export wooden box |
|
After packed size |
2×2.1×1.75M |
3.2×2.1×1.8M |
|
G.W |
830KGS |
1200KGS |
