Model

SKW-1530-5A

Maximum working size:

X Axis: 1500mm Y Axis : 3000mm Z Axis: 850mm  A Axis: ±120°  C Axis: ±213°

Maximum work-piece size:

X Axis: 1500mm Y Axis: 3000mm  Z axis : 700mm (depend on tool length)  A Axis: ±120°  C Axis: ±213°

Table structure:

Movable Table

X, Y, Z Structure:

Taiwan HIWIN rail Guide rail 35,  Germany-made rolling ball screw

Total power:

15KW

Spindle:

10kw, Italy HI-TECO spindle, air-cooled

Auto-tool changing system:

Cloak style ATC with 8 tools in storeroom

Diameter of Cutter:

φ3.175-φ20

Spindle Speed:

22000r/min, variable speed

Working Voltage:

AC380V 50HZ 3-phase

Motor and driver:

YASKAWA Servo motor and driver from Japan

Inverter:

Taiwan-made Delta 15kw inverter

Dictate:

G code

Controlling system:

LNC 5 axis controller

Software:

Alphacam/Powermill

Dust-collect function :

Working table:

T-slot table and Vacuum table.

Max working speed:

X, Y: 30m/min; Z: 10m/min; A, C: 8m/min

Limit:

AUTONICIS

Net weight:

8000kg

Gross weight:

8300kg

Machine size:

6600*1900*3100mm
