功能特点：
1.床身坚固不变形、刚性好、精度高，比普通铁方管床身坚固30%。
2.3轴进口高精度滚珠丝杠,咬合紧密，运动平稳，配合铸铁床身，精度提高20%。
3.0.8KW/1.5KW功率变频水冷主轴，噪音小、强劲有力、免维护、可实现连续作业
4.维宏控制或DSP手柄操作可选，设计人性化，简单易学
5.具有断电记忆，断电续雕，加工时间预测等功能，保证在意外或隔天的情况下加工
6.兼容性强，可兼容TYPE3/ArtCAM/文泰等多种CAD/CAM设计制作软件
7.水槽冷却系统，可适用与所有金属与非金属材料，铜，铝，黄铜等的雕刻雕铣。
技术参数：
|
Model |
SKA-3636L/SKA-4040L/SKA-6090L etc,as user customized |
|
Working Area |
360*360MM |
|
Table Surface |
T-slot table with water tank |
|
Frame |
Strong Cast Iron |
|
X Y Structure |
Ball Screw Drive, HIWIN Rail Linear Bearings |
|
Z Structure |
Taiwan TBI Ball Screw |
|
Spindle Power |
2.2KW Professional Metal Used Spindle(3.2KW 4.5KW Optional) |
|
Spindle Speed |
0-24000RPM |
|
Inverter |
Fuling Inverter(Delta Inverter Optional) |
|
Diver Motors |
Stepper motors and Leadshine Drivers(Servo Motor Optional) |
|
Working voltage |
380V/415V 3 Phase 50/60Hz(Optional:220V Single/3 Phase 50/60Hz or 110V Single Phase 50/60Hz ) |
|
Command Language |
G Code |
|
Operating System |
DSP A11 Control System (Mach 3 Optional) |
|
Software Compatibility |
Artcam (Type 3/UcancameV9 Software) |
|
Computer Interface |
USB |
|
Running Environment Temperature |
0-45 Centigrade |
|
Relative Humidity |
30%-75% |
|
After packed size |
0.81*0.87*1.55M |
|
G.W |
150KGS |
适用行业和材料：
适用于广告业、吸塑灯箱、广告标牌、包装印刷业、有机制品、工艺礼品、竹木制品、塑料木质品材料的加工制作， 可加工有机玻璃、绝缘材料、PVC、亚克力、双色板、ABS板、密度板、木制品，铜章，铝，黄铜等材料的雕刻和雕铣
森科样品展示：
