Main Features:
1 Integrally cast lathe bed, firm and non-deforming, high rigidity and high accuracy, good performance and durability.
2 Unique multi-spindle design, quantity of machine heads and power of spindle can be selected according to the customer's requirements. The distance between spindles can be freely adjusted according to the work piece being processed.
3 One machine can complete the workload of several machines at the same time, saving production time and cost, enhancing the working efficiency
Technical Parameter:
|
Discription |
Parameter |
|
SKW-1325DL |
SKW-1530DL |
SKW-2040DL |
Option |
|
Working Area (X*Y*Zmm) |
1300*2500*200mm |
1500*3000*200mm |
2000*4000*200mm |
customized |
|
Body structure |
Steel wedding |
|
X, Y Structure |
rack and pinion drive |
|
Z Structure |
Ball Screw/option gear-wheel |
|
X, Y Resolution |
<0.01mm |
|
Max Moving Speed |
42000mm/min |
|
Max Engraving Speed |
20000mm/min |
|
Spindle power |
3kw/4.5kw/5.5KW/6KW(can be choices) |
|
Spindle Speed |
6000-24,000rpmrpm |
|
Table style |
Fixture/option vacuum table |
|
Dust collection |
Can add or not |
|
Voltage |
AC220V/50Hz |
|
Drive type |
Stepper/Option:servo |
|
Working Dictate |
G Code ,HPGL |
|
Operating system |
NC-Studio/Dsp System/option syntec or LNC |
|
Interface |
USB |
|
Flash memory |
128M(U Disk) |
|
Software Compatability |
Type3/Ucancam Artcam |
|
Running Enviroment |
Temperature: 0-45 |
Applicable industry:
It is suitable for the wave board processing, wooden door, screen, craft, window processing and different kinds of furniture assistance processing. Also suitable for the aluminium board, plastic board, artificial marble as well as the light metal indus
