fiber 500W/1000W laser metal sheet cutting machine



Features:

1. High accuracy for high precision parts and letter cutting.
2. Fast speed: 100 times speed than wire cutting.
3. Small hot affecting area keeps flat and nice cutting line.
4. High performance to price ratio: the price is only 1/3 of that of CO2 laser cutter and 2/5 of that of CNC.
6. Low maintenance cost: only 1/10~1/15 of same power CO2 laser cutting machine, only 1/3~1/4 of same power.
7. Top Best stable performance fiber module.

TECHNICAL PARAMETERS

Model

Fiber Metal Cutting Machine

SKL500FB-1325

Output Power

500W/1000W

Laser Type

Fiber Laser

Max. Processing Area

1300*2500MM

Max. Cutting Speed

30m/min

Max. No-load Speed

60m/min

Max. Cutting Thickness

6mm

Cutting Seam Width

0.10(depend on the material)

X/Y Axis Positioning Accuracy

0.01mm/m

X/Y Axis Repeated Positioning Accuracy

+0.01mm

Machine Weight

3600kg

Phase

3

Rated Voltage

380V

Frequency

50HZ

Total Power Protection Grade

IP54


Cutting Parameters:

Material

Thickness(mm)

Speed   (m/min)

Cover Gas

Stainless Steel

             0.3

          25

Oxygen

             0.5

          15

Oxygen

             0.7

          12

             0.9

          10

             1.0

           9

             1.2

           7

              2

           5

              3

           2

              4

         1.2

              6

         0.2

              1

         8-9

Nitrogen

              2

        3-3.5

              3

       0.3-0.5

Carbon Steel

              1

         8-9

Oxygen

              2

       2.5-3.5

Oxygen

              3

       2-2.5

              4

       1-1.5

              5

       0.7-1

              6

      0.7-0.9

Aluminum Alloy

              1

           2

Nitrogen

              2

      0.4-0.6

Nitrogen



samples:
