Main Features：
1.DSP/NC-Studio control,support offline work,steel made new dargon gate,strong enough
2. X、Y axes transmission with gear rack, Z axis transmission with imported ball screws, ensures stable and smooth movement of the machine.
3. double open separately control box,beauty,function separately
4. Applicatin of driver with high definition subdivision ensures fast speed and high accuracy.
5. High power spindle, brushless, water cooling/air cooling, working vigorously with low noise.
6. the Y adopt taiwan imported hiwin/pmi square rails,fast speed,high precision
7.with water tank,suitable for all kinds of materials,such as glass,metals,etc
Technical Parameter:
|
Model |
SKS-1325L |
|
X,Y,Z axis workin g area |
1300*2500*200mm |
|
Machine size |
2100*3005*1600 |
|
X,Y movement |
Rack and pinion |
|
Z movement |
Ballscrew transmission |
|
guide |
Taiwan HIWIN/PMI 20 square rails |
|
Max idling speed |
40000mm/min |
|
Max engraving speed |
20000mm/min |
|
Spindle power |
3kw/4.5kw/6kw watercooling/aircooling (choose) |
|
Spindle speed |
24000rpm |
|
inverter |
Fuling2.2kw/ 3.7kw/7.5kw(depend on spindle choose) |
|
Drive motors |
Stepper motor (servo motors optional) |
|
drivers |
Stepper drivers or servo drivers |
|
Control system |
NC-STDUIO (dsp optional) |
|
Working voltage |
220V/380V or customized |
|
Command code |
G code |
|
software |
Artcam,type 3,etc |
|
collet |
ER 25-ER32 |
|
Packing dimension |
3.1*2.1*1.82M |
|
weight |
1200kgs |
|
Standard equipment included |
1.automatic oil injection system
2.Tool sensor
3.T-SLOT table with mechanical clamps |
Applications:
Stone carving machine can meet the requirements of personalized home outfit, tooling design, can be used as a decoration company, stone industry, advanced processing equipment, carving stone industry is suitable for marble, granite, jade, stone, black stone and other stone material, which can realize three-dimensional relief, bottom tip carving, flat, line carve, pour the side carving, drilling, etc., due to the machine with complete functions and so can be used for machining of wood, plastic, glass, ceramic, metal, etc. All materials.
more samples:
