Marble Carving CNC Router

Main Features:
1. nc-studio /DSP control,the strongest steel made new dargon gate,strong enough
       2. X、Y axes transmission with gear rack, Z axis transmission with imported ball screws, ensures stable and smooth movement of the machine.
       3. all in one separately control box,can put computer
       4. Applicatin of driver with high definition subdivision ensures fast speed and high accuracy.
       5. High power spindle, brushless, water cooling/air cooling, working vigorously with low noise.
6. the Y adopt taiwan imported hiwin/pmi square rails,fast speed,high precision
7.strongest body structure,thicked wall never broken or damage
8.with water tank suitable for all kinds of materails work
Technical Parameter:


Model

SKS-1325

SKS-1325

X*Y*Z axis working

1300*2500*300mm

1300*2500*300mm

Table  Size

2100*3005*1600

      Machine frame

Strong steel made/T support heavy duty body

Spindle power

3kw/4.5KW /5.5kw (water cooled)

X*Y*Z movement

Gear rack /Square rail/German Ball Screw

Max move speed

30000mm/min

Max engraving speed

7000mm/min

Spindle speed

0-24000rpm

Control system

NC-Studio control (dsp optional)

 Drive Motors

Stepper(servo motors&drivers optional)

         Cooling system

Water tank,water month and whole cooling system

     Inverter power

Fuling 3.7kw,7.5kw(depend on spindle choose)

Voltage

380V,50Hz/60Hz or customized

     Working Dictate

G code

Software

Artcam Software

     Collet

ER20-32

Packing size

3.1*2.1*1.82M

 3.4*2.25*1.83M

     weight

1200KGS

 1380KGS

    Standard equipment included

1.automatic oil injection system

2.Tool sensor(if needed)

3.water pumps

  Applications:
 Stone carving machine can meet the requirements of personalized home outfit, tooling design, can be used as a decoration company, stone industry, advanced processing equipment, carving stone industry is suitable for marble, granite, jade, stone, black stone and other stone material, which can realize three-dimensional relief, bottom tip carving, flat, line carve, pour the side carving, drilling, etc., due to the machine with complete functions and so can be used for machining of wood, plastic, glass, ceramic, metal, etc. All materials.
