Cylinder engraving cnc router machine

Main feature:

1. transmission with Gemany/taiwan ball screws,Y adopt round rails or square rails,customer choose

2. rotary table,fixed materials automatcally
       3. Application of driver with high definition and subdivision ensures fast speed and high accuracy.
       4. High-speed spindle with water cooling system works vigorously with low noise,guarantee long time mass processing.
       5. Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
       6. Adpot advanced cnc system,configured with practical and easy-learned software,can conveniently check the moving path of tool,and adjust the processing depth of Z axis and the speed of motor

Technical Parameter:



Model

SKR-1200

customized

Rotary diamete

customized according to users

customized

X axis

1200mm or customized according to user needed

Spindle power

0.8kw/1.5kw/2.2kw water cooling(choos)

Spindle speed

0-24,000rpm

X/Y/Z movement

gear rack

X, Y Resolution

0.01mm

Max moving speed

12,000mm/min

Max engraving speed

8,000mm/min

Drive type

Stepper

Inverter power

1.5KW

Working voltage

220V/50-60hz/380v/50hz-60hz/or customized

Working  Dictate

G-code

Operating system

NC-studio control ( DSP optional )

Software

Artcam/Type 3

Collect

ER20-25

Interface

USB

Flash Memory

128M
