Features:
1.All of the spindles can work together to save your time and costs.
2.We can supply 2-14 spindles for a machine.The number and power of the spindle are to be adjusted by the consumer's needs.
3.You can adjust the distance between two spindles to satisfy your requirments.
4.The solid and permanent structure plus unique design make the machine with long service lite performs well.
|
Discription |
Parameter |
|
SKW-1825*8 |
SKW-2025*8 |
SKW-2525*8 |
Option |
|
Working Area (X*Y*Zmm) |
1800*2500*200mm |
2000*2500*200mm |
2500*2500*200mm |
customized |
|
Z Structure |
Ball Screw |
|
X, Y Resolution |
<0.01mm |
|
Max Moving Speed |
32000mm/min |
|
Max Engraving Speed |
20000mm/min |
|
Spindle power |
0.8kw/1.5kw/2.2kw(can be choices) |
|
Table style |
collet/Vacuum table |
|
Spindle Speed |
0-18,000rpmrpm |
|
Dust collection |
Can add or not |
|
Voltage |
AC220V/50Hz |
|
Drive type |
Stepper/Option:servo |
|
Working Dictate |
G Code ,HPGL |
|
Operating system |
NC-Stuido/Dsp option System |
|
Interface |
USB |
|
Flash memory |
128M(U Disk) |
|
Software Compatability |
Type3/Ucancam Artcam |
|
Running Enviroment |
Temperature: 0℃～45℃ |
Applicable industry
Woodworking industry:Classical funitures' processing.
Advertising industry
Advertising signs,logo marking,acrylic cutting,plastic molding,advertising decorative products of different materials.
Other industries: Carving series,relievo series,widly used in handicraft industry
