double engraving and cutting laser machine

Main Features:

1.  with HIWIN high accuracy square rail, perfect performance.
       2. High efficiency tube with stable laser path,
       3. Red cross point offers highest accuracy position.
       4. Professional motion control card offers continue fast curve cutting together with shortest path selection. Shorten work time.

Model

SKLM-9013

SKLM-1414

SKLM-1325

Option

Working Area

900*1300mm

1400*1400mm

1300*2500mm

According to Demands

Laser Power

150w/180w/200w/260w

Laser Type

CO2 Sealed Laser Tube , 10.6μm

Cooling Type

Water Cooling

Engraving Speed

0-60000mm/min

Cutting Speed

0-40000mm/min

Laser Output Control

0-100% set by software

Min. Engraving Size

Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm

Highest Scanning Precision

4000DPI

Locating Accuracy

≤+0.01mm

Controlling Software

DSP Control System

Graphic Format Supported

DST PLT BMP DXF DWG AI LAS,etc

Compatible Software

CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.

Color Separation

Yes

Drive System

High-precision 3-phase Stepper Motor

Auxiliary Equipments

Exhaust Fan and Air Exhaust Pipe

Power Supply

AC110V/220V+10%,50HZ/60HZ

Working Environment

Temperature:0-45C,Humidity 5-95%(No Condensate Water)
