machine with autofeeding for roll materilas mark, while person sleepping the machines still working, working video as below:
https://youtu.be/ybGKqq9sUx0
Main Features:
1. High quality laser path suitable for delicate marking.1/4 of diode laser.
2. stable power bring high speed laser marking. Unit pulse power surge is lower than 1%. Easy control laser dot size, thickness and shape.
3. High speed 2-3 times over than traditional diode pumped marking machine.
4. Air-cooling smart machine size and weight
5. Long lifetime.
Technical Parameter:
|
Model |
SKD-20W |
SKD-30W |
SKD-50W |
|
Laser Power |
20W |
30W |
50W |
|
Laser Wavelength |
1064nm |
|
Q-frequency |
20KHz~30KHz |
|
Divergence |
0.3mard |
|
Marking Range |
100*100mm |
|
Minimum Line Width |
0.02mm |
|
Minimum Character |
0.15mm |
|
Marking Depth |
0 ~0.5mm |
|
Engraving Line Speed |
≤7000mm/s |
|
Repeatability Accuracy |
±0.001mm |
|
Beam Quality |
M2:1.2~1.8 |
|
Marking Format |
Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date,Batch Number,Serial Number,Frequency,etc. |
|
Graphic Format Supported |
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. |
|
Working Voltage |
220V±10%/50Hz/4A |
|
Unit Power |
＜0.5kw |
|
Working Condition:Humidity |
5%-75%，Free of Condensed Water |
