Main Features:
1. High quality laser path suitable for delicate marking.1/4 of diode laser.
2. stable power bring high speed laser marking. Unit pulse power surge is lower than 1%. Easy control laser dot size, thickness and shape.
3. High speed 2-3 times over than traditional diode pumped marking machine.
4. Air-cooling smart machine size and weight
5. Long lifetime.
Technical Parameter:
|
Model |
SKD-20W/30W/50W etc,as user customized |
|
Laser Power |
20w Raycus brand optical fiber laser generator |
|
Work size |
110×110/200*200/300*300MM/optional |
|
Interface |
USB |
|
Cooling type |
air cooling |
|
Minimum Line Width |
0.01mm |
|
Minimum Character |
0.15mm |
|
Marking Depth |
0~0.5mm |
|
Engraving Line Speed |
≤7000mm/s |
|
Repeatability Accuracy |
±0.001mm |
|
Beam Quality |
M2:1.2~1.8 |
|
Graphic Format Supported |
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. |
|
Voltage |
220v/single or 380v/3phase or as customer needed |
|
Unit Power |
<0.5kw |
|
Working Condition:Humidity |
5%-75%,Free of Condensed Water |
|
Operating system |
Ezcard |
|
computer |
can choose or not |
|
Model |
SKD-20W |
|
Laser Power |
20w Raycus brand optical fiber laser generator |
|
Work size |
110×110/200*200/300*300MM/optional |
|
Interface |
USB |
|
Cooling type |
air cooling |
|
Minimum Line Width |
0.01mm |
|
Minimum Character |
0.15mm |
|
Marking Depth |
0~0.5mm |
|
Engraving Line Speed |
≤7000mm/s |
|
Repeatability Accuracy |
±0.001mm |
|
Beam Quality |
M2:1.2~1.8 |
|
Graphic Format Supported |
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. |
|
Voltage |
220v/single or 380v/3phase or as customer needed |
|
Unit Power |
<0.5kw |
|
Working Condition:Humidity |
5%-75%,Free of Condensed Water |
|
Operating system |
Ezcard |
|
computer |
can choose or not |
