Model |
SKQ-1313 |
SKQ-1325 |
|
Cutting area (X*Y) |
1300*1300mm |
1300*2500mm |
|
X Y Z Movement |
Imported Gear Rack |
Imported Gear Rack |
|
Z Structure |
Taiwan ball screw |
Taiwan ball screw |
|
XYZ rails |
Taiwan HIWIN square rails |
Taiwan HIWIN square rails |
|
Max Moving Speed |
20000mm/min |
20000mm/min |
|
Max Engraving Speed |
12000mm/min |
12000mm/min |
|
Voltage |
220v/single or 380v/3phase or as customer needed |
220v/single or 380v/3phase or as customer needed |
|
Drive type |
Stepper motors and leadshine drivers |
Stepper motors and leadshine drivers |
|
Working Dictate |
G Code |
G Code |
|
Operating system |
Professional Glass cutting operating system |
Professional Glass cutting operating system |
|
Software |
Professional Glass cutting software |
Professional Glass cutting software |
|
Working table |
Professional glass protection working table |
Professional glass protection working table |
|
Minimum glass size |
1x1mm |
1x1mm |
|
Wire protect |
Yes,included |
Yes,included |
|
Package |
Export wooden box |
Export wooden box |
|
After packed size |
2×2.1×1.75M |
3.2×2.1×1.8M |
|
G.W |
830KGS |
1200KGS |
