Main features:
1. Nc-studio /DSP control, the strongest steel new gantry, strong enough
2. X and Y axis drive with rack and pinion, Z axis drive with imported ball screw, to ensure smooth machine movement.
3. Independent control box for all - in - one computer
4. Application of HD subdivision driver, fast speed, high precision.
5, high power spindle, brushless, water cooling/air cooling, strong operation, low noise.
6. Y adopts Hiwin/PMI square rail imported from Taiwan, with high speed and precision
7. The strongest body structure, the thick wall will never break or damage
8. Water tank is suitable for all kinds of materials
|
Model |
SKS-9015 |
SKS-1325 |
Customized |
|
Working area (X*Y*Z) |
900*1500*300mm |
1300*2500*300mm |
According to Size |
|
Body structure |
Iron casted,strong enough for metals work |
Iron casted,strong enough for metals work |
Iron casted,strong enough for metals work |
|
X, Y, Z Structure |
Taiwan HIWIN square rails |
Taiwan HIWIN square rails |
Taiwan HIWIN square rails |
|
X, Y Resolution |
<0.03mm |
<0.03mm |
<0.03mm |
|
Max Moving Speed |
18000mm/min |
18000mm/min |
18000mm/min |
|
Max Engraving Speed |
10000mm/min |
10000mm/min |
10000mm/min |
|
XYZ traveling positioning accuracy |
±0.01mm |
±0.01mm |
±0.01mm |
|
XYZ repositioning accuracy |
±0.01mm |
±0.01mm |
±0.01mm |
|
Spindle power |
3.0kw stone professional use spindle(optional) |
3.0kw stone professional use spindle(optinal) |
3.0kw stone professional use spindle(optinal) |
|
Spindle Speed |
0-24,000rpm |
0-24,000rpm |
0-24,000rpm |
|
Voltage |
110V/220v/380v(choice) |
110V/220v/380v(choice) |
110V/220v/380v(choice) |
|
Drive type |
Leadshine stepper/ servo motors and drivers |
Leadshine stepper/ servo motors and drivers |
Leadshine stepper/ servo motors and drivers |
|
Working Dictate |
G Code |
G Code |
G Code |
|
Operating system |
NC -Studio/DSP A11/MAch3,etc |
NC -Studio/DSP A11/Mach3,etc |
NC -Studio/DSP A11/Mach3,etc |
|
Interface |
USB |
USB |
USB |
|
Table |
T-slot table with clamps |
T-slot table with clamps |
T-slot table with clamps |
|
Package size |
3.4*2.05*1.89M |
3.7*2.16*1.89M |
According to size |
|
G.W |
900KGS |
1400KGS |
According to size |
