Mini cnc wood router 6090

Main feature:

1. transmission with Gemany/taiwan ball screws,Y adopt round rails or square rails,customer choose

2. vacuum table,fixed materials automatcally
3. Application of driver with high definition and subdivision ensures fast speed and high accuracy.
4. High-speed spindle with water cooling system works vigorously with low noise,guarantee long time mass processing.
5. Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
6. Adpot advanced cnc system,configured with practical and easy-learned software,can conveniently check the moving path of tool,and adjust the processing depth of Z axis and the speed of motor

Technical Parameter:

Model

SKA-6090

customized

X/Y/Z working size

600*900*150mm

customized

Table size

1250*930*1120mm

Spindle power

0.8kw/1.5kw/2.2kw water cooling(choos)

Spindle speed

0-24,000rpm

X/Y/Z movement

Taiwan/Germany ball screw

X, Y Resolution

0.05mm

Max moving speed

12,000mm/min

Max engraving speed

8,000mm/min

Drive type

Stepper

Inverter power

1.5KW

Working voltage

220V/50-60hz/380v/50hz-60hz/or customized

Working  Dictate

G-code

Operating system

NC-studio control ( DSP optional )

Software

Artcam/Type 3

Table type

Vacuum table

Collect

ER20-25

Interface

USB

Flash Memory

128M

Packing size (W*L*H)

1.22*1.46*1.72M

Gross weight

290KGS

Applications:

Advesting industry,artcraft industry,various types of man-made plate,LED,light box,building modes,rulers badges,department cards etc

wood,pvc board,MDF board,PCB board,aluminum industry,3D technology,breastplate,indoor&outdoor decoration etc
