1325 cnc router machine with rotary inside body

Main Features:
1.original nc-studio control,steel made new dargon gate,strong enough
       2. X、Y axes transmission with gear rack, Z axis transmission with imported ball screws, ensures stable and smooth movement of the machine.
       3. all in one separately control box,can put computer
       4. Applicatin of driver with high definition subdivision ensures fast speed and high accuracy.
       5. High power spindle, brushless, water cooling/air cooling, working vigorously with low noise.
6. the Y adopt taiwan imported hiwin/pmi square rails,fast speed,high precision
7.strongest body structure,thicked wall never broken or damage
Technical Parameter:


Model

SKW-1325  SKW-1530/SKW-2040 etc,as user customized

X,Y,Z axis workin g area

1300*2500*200mm

Table Surface

T-slot working table with hard black PVC

Body structure

Thicken steel Big and heavy tube made body

Frame

New style heavy duty welded

Leg pad

depth 10MM

X, Y Structure

gear rack, Hiwin rail line bearings

rails

Original Taiwan HIWIN blocks with

original stamp use on rails

Gear rack

Gear rack with pingchuan brand

Z Structure

25mm Taiwan TBI ball screw

X, Y Resolution

<0.01mm

Max Moving Speed

70000mm/min

Max Engraving Speed

50000mm/min

XYZ traveling positioning accuracy

±0.01mm

Spindle power

4.5 KW HQD air cooling spindle(5.5

/6/9KW optional)/water cooling optional

Spindle Speed

0-18,000rpm

Inverter

Fuling inverter(Delta inverter optional)

Voltage

110v/220v/380v/415v , 50HZ/60HZ,

1phase/3phase

Motor&Drive type

Stepper motors & Lead shine drivers

Working  Dictate

G Code

Operating system

DSP A11 control system(NC-Studio/MACH3 optional)

Computer interface

USB

software

Artcam(Type 3/ JDpaint optional)

Tool sensor

Yes ,included

oil lubricator

Yes ,included

Wire protect

Yes ,included

Running Environment

Temperature: -10℃45℃

Relative humidity

30%-75%

After packed size

3.2*2.18*1.90M

G.W

1200kgs




Applications:
 Woodworking industry: wood crafts, picture frames cutting, handicraft carving wave plates, wooden door production and processing (density board and particieboard, sandwich plate, cutting, making violin surface, solid wood furniture, carved wood art murals carved, guide plate processing, avoid lacquer carved door, cabinet door, craft wooden door, wenqi door, screen, PP plate cutting, the process window processing, aluminum plate cutting, calligraphy carving made three-dimensional wave board processing, wooden door, screen, process window, small handicraft processing, large area of plate plane sculpture, secondary processing of various kinds of wooden products, furniture products.

Advertising industry: advertising materials such as PVC, acrylic, double color plate processing
