CNC mould engraving machine

Main features:

1. NC-Studio or dsp operate with easy learn,fully function,.
2..aricold or watercold spindle,supply enough strong power,stably run and use,at the same time higher precision
 3. japan imported yaskawa servo motors and drivers for optional,high speed,long life and higher precision
 4.big size gear rack keep the machine run stabely
 5.Taiwan imported hiwin/pmi  square rails.
 6.dust collect and vacuum table for optional choose
Technical Parameter:


Model

SKW-1325F/SKW-1530F/SKW-2030F etc

X,Y,Z axis workin g area

1300*2500*500mm

X,Y movement

Rack and pinion

Z movement

Ballscrew transmission

Guide

Taiwan HIWIN/PMI 25-30 square rails

Max idling speed

60000mm/min

Max engraving speed

30000mm/min

Spindle power

7.5kw spindle

Spindle speed

18000rpm

inverter

11kw

Drive motors

Japan Yaskawa servo motors

drivers

Servo drivers

Control system

Taiwan SYNTEC control

Working voltage

380V or customized

Command code

G code

software

Artcam,type 3,etc

collet

ER32-ER40

Standard equipment included

1.automatic oil injection system

2.Tool sensor









































Applicable industry:

 1 mould industry: carving various mould, such as auto mould, big ship foam block, aviation block, propellers, block the train.
   2. Musical Instruments industry: can be carved large instruments 3 d surface, appearance cutting
