Mini Metal engraving machine

Main feature:

1. transmission with Gemany/taiwan ball screws,keeping high precision and working stably

2. T-slot table,suitable for all kinds of materials
       3.with wate tank etc watercoolin system,suitable for both metals and non-metals materials
       4.table move with the most highest working precison,at the sam time,the LED light support day and night work
       5. Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
       6. Adpot advanced cnc system,configured with practical and easy-learned software,can conveniently check the moving path of tool,and adjust the processing depth of Z axis and the speed of motor

Technical Parameter:



Model

SKA-3636L/SKA-4040L/SKA-6090L etc,as user customized

Working Area

360*360MM

Table Surface

T-slot table with water tank

Frame

Strong Cast Iron

X Y Structure

Ball Screw Drive, HIWIN Rail Linear Bearings

Z Structure

Taiwan TBI Ball Screw

Spindle Power

2.2KW Professional Metal Used Spindle(3.2KW 4.5KW Optional)

Spindle Speed

0-24000RPM

Inverter

Fuling Inverter(Delta Inverter Optional)

Diver Motors

Stepper motors and Leadshine Drivers(Servo Motor Optional)

Working voltage

380V/415V 3 Phase 50/60Hz(Optional:220V Single/3 Phase 50/60Hz or 110V Single Phase 50/60Hz )

Command Language

G Code

Operating System

DSP A11 Control System (Mach 3 Optional)

Software Compatibility

Artcam (Type 3/UcancameV9 Software)

Computer Interface

USB

Running Environment Temperature

0-45 Centigrade

Relative Humidity

30%-75%

After packed size

0.81*0.87*1.55M

G.W

150KGS

 SenKe sampls show:
